【technical parameter】

   Measuring range: 0-100%
   Working life: 6 years
   Signal output: 12.5-16.5mV
   Resolution: 0.1%
   Working temperature: 10℃-40℃
   Working pressure: 700-1250 hPa
   Response time (T90): <12s
   Signal attenuation: <1%/month
   Humidity range: -0.03%/1%RH
   Linearity error: <03%
   Load resistance: >10KΩ
   Temperature compensation: with
   Connection port: 3P gold-plated pin socket



  【main application】

   It is widely used in anesthesia machines, incubators, ventilators and oxygen monitors.
